NetLinx® Integrated Control
149
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Setting a Static IP Address
The current IP address is displayed on the Network Settings page.
Note: When the TCP/IP connection is made, the DHCP server on the network automatically assigns an IP
address. If you power down and power back up, the DHCP server will reassign the IP address, which may or
may not be the same address it assigned previously. Setting a static IP address prevents the possibility of the
IP address changing at power up.
To enter a static IP address:
1.
From the Devices drop-down list in the upper right-hand corner, select NI Master.
The Network Settings page opens.
2. If Specify IP Address is not selected under IP Address, click to enable.
3. Enter the static IP address in the IP Address fields.
4. Click Accept.
5. Click Reboot.
Important: Any time you click “Reboot” from any page in the WebConsole, the server reboots. The reboot
updates information between the Enova DGX Master and the server. The Enova DGX Switcher itself does not
reboot.
Note: A static IP address can also be set without using a DHCP server by following the directions on the next
page.
FIG. 86 Network Settings page with static IP Address
Click to specify IP Address
Enter Static IP Address
To Next Page
