Page #213 background image
Appendix D – Programmer’s Interface for System Diagnostics
213
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Component Identity Settings
Detailed information for a single system component can be specified by using its identity (i) number setting
(i1 through i7) in the following table. Minimal information for all seven components can be specified by using the
identity number i0.
Default Settings
At system boot, the ~scrv0i1 setting is displayed (FIG. 118 on page 214).
If the verbosity setting is omitted, the verbosity level will be the lowest (v0).
The component setting must be included; otherwise, entering any of the verbosity settings alone will result in
a display equivalent to v0i0.
If both settings are omitted during a query (~scr!), the information displayed will be at the lowest verbosity
level for all components (v0i0) (FIG. 117 on page 212).
Using BCS to Access System Diagnostic Information
Instructions are given for accessing the lowest level of verbosity for all components and for accessing a specific level of
verbosity for a specific component.
To access the lowest level of verbosity for all components:
1.
Enter ~scr! or ~scrv0i0!
Note: Either of these commands provides a “menu” of the identity numbers and their corresponding
components (FIG. 117 on page 212).
Only one verbosity setting and one component setting can be entered in a command. The order in which the verbosity
and component settings are entered is interchangeable.
To access a specific level of verbosity for a specific component:
1.
Enter ~scr (to access the splash screen).
2. Enter the verbosity level setting v# and the component identity setting i#.
Either may be specified first.
3. Enter ! (to send the command).
Example
~scrv3i6! or ~scri6v3! (Either displays the highest level of detail for the Power System.)
Component Identity Number
All Components i0
Enclosure i1
Storage Blocks i2
Communication Interfaces i3
Hardware / Boards i4
VM Configuration i5
Power System i6
System Sensors i7
