Installation and Setup
34
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Options for System Setup with DXLink™ Twisted Pair
The following table contains the options in an Enova DGX Switcher for using DXLink™ Input and Output Boards in
conjunction with DXLink™ Transmitters and Receivers.
Note: DXLink Modules can also be used as a standalone, end-to-end solution; see the “Instruction Manual –
DXLink™ Twisted Pair Transmitters/Receiver.”
* If the board is an SC Optical Board it will need the appropriate DGX Fiber Module; see table below.
A typical system setup for a source and destination is illustrated on page 91 and shows an Enova DGX 16 with DXLink
Boards used in conjunction with DXLink HDMI Transmitters and Receivers.
Options for System Setup with DXLink™ Fiber
The following table contains the options in an Enova DGX Switcher for using DXLink™ Fiber Input and Output Boards
in conjunction with DXLink™ Fiber Transmitters and Receivers.
** If the board is a DXLink Twisted Pair Board it will need the appropriate DXLink Twisted Pair Module; see the table above.
If the board is an SC Optical Board it will need the appropriate DGX Fiber Module; see the table on the following page.
A typical system setup for a source and destination is illustrated on page 105 and shows an Enova DGX 16 with DXLink
Fiber Boards used in conjunction with DXLink Fiber Transmitters and Receivers.
System Setup Options – Enova DGX Boards with DXLink Modules/Wallplates
DXLink Module/Wallplate Enova DGX Input Board Enova DGX Output Board DXLink Module
HDMI TX Module DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
HDMI TX Modules DXLink Twisted Pair Any output board* Not applicable
Multi-Format TX Module DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
Multi-Format TX Module DXLink Twisted Pair Any output board* Not applicable
Multi-Format Wallplate TX DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
Multi-Format Wallplate TX DXLink Twisted Pair Any output board* Not applicable
Decor Wallplate TX DXLink Twisted Pair DXLink Twisted Pair HDMI RX Module
Decor Wallplate TX DXLink Twisted Pair Any output board* Not applicable
Not Applicable Any input board* DXLink Twisted Pair HDMI RX Module
Caution: If you plan to connect switching systems via their DXLink ports, be sure to read the information on
page 94.
System Setup Options – Enova DGX Boards with DXLink Fiber, Duplex Units
DXLink Fiber TX DXLink Fiber Input Board DXLink Fiber Output Board DXLink Fiber RX
Multi-Format MM Fiber TX Multimode Fiber, Duplex Multimode Fiber, Duplex HDMI MM Fiber RX, Duplex
Multi-Format MM Fiber TX Multimode Fiber, Duplex Single Mode Fiber, Duplex HDMI SM Fiber RX, Duplex
Multi-Format MM Fiber TX Multimode Fiber, Duplex Any output board** Not applicable
Multi-Format SM Fiber TX,
Duplex
Single Mode Fiber, Duplex Single Mode Fiber, Duplex HDMI SM Fiber RX, Duplex
Multi-Format SM Fiber TX,
Duplex
Single Mode Fiber, Duplex Multimode Fiber, Duplex HDMI MM Fiber RX, Duplex
Multi-Format SM Fiber TX,
Duplex
Single Mode Fiber, Duplex Any output board** Not applicable
Not applicable Any input board** Multimode Fiber, Duplex HDMI MM Fiber RX, Duplex
Not applicable Any input board** Single Mode Fiber, Duplex HDMI SM Fiber RX, Duplex
