Product Overview and General Specifications
12
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Product Overview and General Specifications
Applicability Notice
The information in this manual applies to the following Enova
®
DGX Digital Media Switcher enclosures, plus input,
output, and expansion boards, which can be ordered to create custom systems. All of the boards are compatible with any
Enova DGX enclosure.
Note: All Enova DGX Switchers ship with a standard front control panel.
Enova DGX 8 Enclosure (4 RU)
Enova DGX 16 Enclosure (4 RU)
Enova DGX 32 Enclosure (6 RU)
Enova DGX 64 Enclosure (13 RU)
* While these new enclosures continue to utilize existing Enova DGX input and output boards, they are optimized and ready
for 4K board solutions.
Enova DGX Digital Media Switchers Standard Input and Output Boards
Enova DGX Switchers currently support four standard Enova input and output board types: DVI, HDMI, DXLink
Twisted Pair, DXLink Fiber, as well as Epica DGX SC Optical Boards. Each board fills one of the standard I/O board
slots and has four connectors. Within a system, a source device connected to any of the input boards can be routed to any
destination device connected to any of the output boards (check the board chapters for important signal information
when routing between board types).
For general board information, see page 20 and page 40.
For specific board information, see the applicable board chapter in this manual.
Enova DGX HDMI Boards (page 70)
Enova DGX DVI Boards (page 79)
Configuration FG # Model
8x8 FG1058-08 AVS-ENOVADGX8-ENC (ENOVA DGX 8 ENC)
8x8 FG1058-09* ENOVADGX8-ENC-A (ENOVA DGX 8 ENC)
Configuration FG # Model
16x16 FG1058-16 AVS-ENOVADGX16-ENC (ENOVA DGX 16 ENC)
16x16 FG1058-17* ENOVADGX16-ENC-A (ENOVA DGX 16 ENC)
Configuration FG # Model
32x32 FG1059-33* AVS-ENOVADGX32-ENC-A (ENOVA DGX 32 ENC)
Configuration FG # Model
64x64 FG1060-64* ENOVADGX64-ENC (ENOVA DGX 64 ENC)
Type FG # Model
HDMI w/ HDCP Input FG1058-540 AVS-ENOVADGX32-VI-HDMI
HDMI w/ HDCP and SmartScale Output FG1058-550 AVS-ENOVADGX32-VO-HDMI
Type FG # Model
DVI w/HDCP Input FG1058-600 AVS-ENOVADGX32-VI-DVI
DVI w/HDCP and SmartScale Output FG1058-610 AVS-ENOVADGX32-VO-DVI
