Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Enova DGX 16 – General Specifications
AMX reserves the right to modify its products and their specifications without notice.
General Specifications
Parameter Value
Approvals UL 60950-1, CSA 60950-1, IEC 60950-1, CE EN 60950-1,
CE EN 55022 Class A, CE EN 55024, FCC CFR Title 47 Part 15
Subpart B Class A, ICES-003 Class A, RoHS, WEEE
AC Power 100 VAC to 240 +/-10% VAC single phase, 50/60 Hz
Power Capacity (max.) 977 Watts, with redundancy
Power Consumption (max.) 835 Watts, fully loaded DXLink Power enclosure with redundancy
Power Consumption (typical) 362 Watts, fully loaded HDMI enclosure with redundancy
Thermal Dissipation Full Capacity (max.) 3334 BTU/hr., with redundancy
Thermal Dissipation (max.) 2849 BTU/hr., fully loaded DXLink Power enclosure with redundancy
Thermal Dissipation (typical) 1235 BTU/hr, fully loaded HDMI enclosure with redundancy
Power Factor Correction (PFC) Supported, complies with EN60555-2 and EN61000-3-2
Operational Temperature 32° F to 104° F (0° C to 40° C)
Storage Temperature -22° F to 158° F (-30° C to 70° C)
Operational Humidity 5% to 85% RH (non-condensing)
Storage Humidity 0 to 90% RH (non-condensing)
MTBF 168,000 hrs.
Dimensions 15 in. (38.1 cm) depth; 16 in. (40.64 cm) depth with extractors
19 in. (48.26 cm) width including integral rack mounting ears
6.84 in. (17.37 cm) height (4 RU)
Weight Approximately 55 lb. (24.95 kg) per loaded enclosure
Shipping Weight Approximately 65 lb. (29.5 kg) per loaded enclosure
Per Channel Aggregate Data Rate (max.) 12.8 Gbps
Noise Level <52.5 dBA @ 1 m (typical @ 25° C)
Airflow Forced air (inlet on side; exhaust on side)
Compatible DXLink™ Twisted Pair Transmitters
and Receivers
• DXLink Multi-Format Transmitter Modules
• DXLink HDMI Transmitter Modules
• DXLink Multi-Format Wallplate Transmitters
• DXLink Multi-Format Decor Style Wallplate Transmitter (US)
• DXLink HDMI Receiver Modules
Compatible DXLink™ Fiber Transmitters and
Receivers
• DXLink Multi-Format MM Fiber TX, Duplex
• DXLink Multi-Format SM Fiber TX, Duplex
• DXLink HDMI MM Fiber RX, Duplex
• DXLink HDMI SM Fiber RX, Duplex
Compatible DGX Fiber Transmitters and Receivers • DGX Fiber DVI Transmitter and Receiver Modules
• DGX Fiber HD-15 Transmitter and Receiver Modules
