Enova DGX DXLink™ Fiber Boards, Duplex
101
Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Enova DGX DXLink™ Fiber Boards, Duplex – Specifications
Applies to multimode boards FG1058-622 (input) and FG1058-632 (output) and single mode boards FG1058-620
(input) and FG1058-630 (output).
Compatible AMX DXLink Fiber Products
Fiber optic transceivers are self-contained modules that send and receive optical signals over fiber cable. DXLink SFP+
fiber optic transceivers* are either multimode or single mode and must be wired with the corresponding cable type.
* SFP+ = enhanced small form-factor pluggable fiber optic transceiver rated at 10 Gbps transmission data rate.
Compatibility Note: The DXLink Fiber Input Board, Duplex and its DXLink Fiber TX, Duplex must
have the
same type of fiber optic transceiver: either multimode or single mode. The same holds true for DXLink Fiber
Output Boards, Duplex and their DXLink Fiber RX, Duplex units.
* Connectivity between products requires matching model types, multimode to multimode or single mode to single mode.
** The scaler on the corresponding output board or DXLink Fiber RX must be set to Bypass mode.
^ The scaler on the corresponding output board or DXLink Fiber RX must be set to Bypass mode using CEA-861 formats
and the resolution is 1080p @60 or less.
^^ Input signal support is for YCbCr 4:4:4 and 4:2:2; output color-space is converted to RGB 4:4:4.
AMX reserves the right to modify its products and their specifications without notice.
DXLink Fiber Board, Duplex and DXLink Fiber TX/RX, Duplex – Compatibility
Transceiver Type Enova DGX DXLink Fiber Board, Duplex and Part # DXLink Fiber, Duplex Units and Part#
Multimode MMF-D Input Board (FG1058-622) DXLF-MFTX-MM-D (FG1010-362)
MMF-D Output Board (FG1058-632) DXLF-HDMIRX-MM-D (FG1010-562)
Single Mode SMF-D Input Board (FG1058-620) DXLF-MFTX-SM-D (FG1010-360)
SMF-D Output Board (FG1058-630) DXLF-HDMIRX-SM-D (FG1010-560)
DXLink Fiber, Duplex – Specifications
Parameter Value
Compatible Formats HDMI video, audio, Ethernet, USB (HID), control
Signal Type Support DXLink Fiber*
Transport Layer Throughput 10.3125 Gbps
Video Data Rate (max.) 4.95 Gbps / 5.568 Gbps^
Video Pixel Clock (max.) 165 MHz / 185.625 MHz^
Progressive Resolution Support 480p up to 1920x1200 @ 60 Hz
Interlaced Resolution Support 480i, 576i, 1080i
Deep Color Support 24-bit, 30-bit^
Color Space Support RGB 4:4:4
YCbCr^^ 4:4:4 and 4:2:2
3D Format Support Yes**
Frame Packing 1080p up to 24 Hz
Frame Packing 720p up to 50/60 Hz
Frame Packing 1080i up to 50/60 Hz
Top-Bottom 1080p up to 24 Hz
Top-Bottom 720p up to 50/60 Hz
Side-by-Side Half 1080i up to 50/60 Hz
Compatibility Note
