Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Enova DGX 64 – General Specifications
AMX reserves the right to modify its products and their specifications without notice.
General Specifications
Parameter Value
Approvals UL 60950-1, CSA 60950-1, IEC 60950-1, CE EN 60950-1,
CE EN 55022 Class A, CE EN 55024, FCC CFR Title 47 Part 15
Subpart B Class A, ICES-003 Class A, RoHS, WEEE
AC Power 100 VAC to 240 +/-10% VAC single phase, 50/60 Hz
Power Capacity (max.) 3960 Watts, @ 110 VAC
5189 Watts, @ 230 VAC
Power Consumption (max.) 3240 Watts, fully loaded DXLink Power enclosure
Power Consumption (typical) 1024 Watts, fully loaded HDMI enclosure
Thermal Dissipation Full Capacity (max.) 13524 BTU/hr, @ 110 VAC
17721 BTU/hr, @230 VAC
Thermal Dissipation (max.) 11065 BTU/hr, fully loaded DXLink Power enclosure
Thermal Dissipation (typical) 3497 BTU/hr, fully loaded HDMI enclosure
Power Factor Correction (PFC) Supported, complies with EN60555-2 and EN61000-3-2
Operational Temperature 32° F to 104° F (0° C to 40° C)
Storage Temperature -22° F to 158° F (-30° C to 70° C)
Operational Humidity 5% to 85% RH (non-condensing)
Storage Humidity 0 to 90% RH (non-condensing)
Dimensions 20.08 in. (51 cm) depth; 21.08 in. (53.54 cm) with extractors
19 in. (48.26 cm) width with rack mounting ears
22.75 in. (57.79 cm) height (13 RU)
Weight Approximately 150 lb. (68.0 kg) per loaded enclosure
Shipping Weight Approximately 257 lb. (116.6 kg) per loaded enclosure
MTBF 86,000 hrs
Per Channel Aggregate Data Rate (max.) 26 Gbps
Noise Level <50.1 dBA @ 1 m (typical @ 25° C)
Airflow Forced air (inlet on sides; exhaust on back and top)
Compatible DXLink™ Twisted Pair Transmitters
and Receivers
• DXLink Multi-Format Transmitter Modules
• DXLink HDMI Transmitter Modules
• DXLink Multi-Format Wallplate Transmitters
• DXLink Multi-Format Decor Style Wallplate Transmitter (US)
• DXLink HDMI Receiver Modules
Compatible DXLink™ Fiber Transmitters and
Receivers
• DXLink Multi-Format MM Fiber TX, Duplex
• DXLink Multi-Format SM Fiber TX, Duplex
• DXLink HDMI MM Fiber RX, Duplex
• DXLink HDMI SM Fiber RX, Duplex
Compatible DGX Fiber Transmitters and
Receivers
• DGX Fiber DVI Transmitter and Receiver Modules
• DGX Fiber HD-15 Transmitter and Receiver Modules
