Instruction Manual – Enova DGX 8/16/32/64 Digital Media Switchers
Enova DGX DXLink™ Twisted Pair Boards* (page 84)
* Enova DXLink™ Twisted Pair Boards must be used in conjunction with DXLink™ Twisted Pair Transmitters and
Receivers or other AMX DXLink™ signal management solutions. For model numbers of compatible Transmitters and
Receivers, see page 86. For system setup information, see page 90.
Enova DGX DXLink™ Fiber Boards** (page 99)
** Enova DXLink™ Fiber Boards must be used in conjunction with DXLink™ Fiber Transmitters and Receivers. For model
numbers of compatible Transmitters and Receivers, see page 101. For system setup information, see page 105.
Epica DGX SC Optical Boards^ (page 114)
^ Epica DGX SC Optical Boards work in Enova DGX enclosures and must be used in conjunction with DGX Fiber
Transmitters and Receivers. For model numbers of compatible modules, see page 115. For system setup information,
see page 116.
Enova DGX Expansion Boards
Enova DGX Switchers currently support the Audio Insert/Extract Board. This board can be installed in either or both
of the expansion slots. The Audio Insert/Extract Board will not fit in a standard input or output board slot.
Enova DGX Audio Insert/Extract Board (page 119)
^^ AIE Board FG1058-705 is compatible with the Enova DGX 8/16/32/64, replacing AIE Board FG1058-700 (discontinued)
which was compatible with the Enova DGX 8/16/32 only.
Product Notes
The Enova DGX Digital Media Switcher includes an integrated NetLinx Central Control Processor, supports
InstaGate Pro
®
, DXLink™ Technology, and SmartScale
®
on every output, and manages and distributes analog and
digital audio and video including HDMI/HDCP, control, and Ethernet.
The Enova DGX Switcher is available as a custom system, which means it can be ordered in input to output
configuration sizes that fit your installation and contain an assortment of input, output, and expansion boards in a single
enclosure.
Note: Because Enova DGX Switchers are available as custom systems, the illustrations in this manual may
differ from the model(s) you purchased.
Features of the Enova DGX Digital Media Switcher
HDMI, DVI, DXLink™ Twisted Pair, DXLink™ Fiber, and Audio
True HDMI switching, allowing any input to be switched to any or all outputs (including SC Optical).
Incorporates HDMI
®
technology – HDMI, DVI, DXLink™ Twisted Pair, and DXLink™ Fiber Boards.
HDCP 1.4 compatible (all boards except SC Optical Boards which cannot pass HDCP).
Type FG # Model
DXLink w/HDCP Input FG1058-570 AVS-ENOVADGX32-VI-DXLINK
DXLink w/HDCP Output FG1058-580 AVS-ENOVADGX32-VO-DXLINK
Type FG # Model
DXLink Multimode Fiber Input Board, Duplex FG1058-622 ENOVADGX-VI-DXLINK-MMF-D
DXLink Multimode Fiber Output Board, Duplex FG1058-632 ENOVADGX-VO-DXLINK-MMF-D
DXLink Single Mode Fiber Input Board, Duplex FG1058-620 ENOVADGX-VI-DXLINK-SMF-D
DXLink Single Mode Fiber Output Board, Duplex FG1058-630 ENOVADGX-VO-DXLINK-SMF-D
Type FG # Model
SC Optical Input FG1056-500 AVS-EPDGX32-OI-SC
SC Optical Output FG1056-510 AVS-EPDGX32-OO-SC
Type FG # Model
Audio Insert/Extract FG1058-705^^ AVS-ENOVADGX-AUD-INS-EXT

AMX Enova DGX 8 Specifications

General

Brand	AMX
Model	Enova DGX 8
Category	Switch
Language	English
