Firmware Pages and Descriptions
123
10" Modero Touch Panels
FIG. 112 Wireless Settings page - EAP-TTLS security method
Wireless Security - EAP-TTLS Settings
SSID (Service Set Identifier): The SSID is the unique name used on the WAP and then assigned to all
panels in a wireless network that are communicating to the same target WAP.
• This is required by the WAP before the panel is permitted to join the
wireless network.
• It is case sensitive and must not exceed 32 characters, which may be any
keyboard character. Make sure this setting is the same for all points in your
wireless network.
• This unique string identifies the network and is the same string for all users
on the same network.
• Use the on-screen keyboard’s Clear button to completely erase any
previously stored SSID information.
Note: In all cases, the SSID of the WAP must be entered. If it is left blank,
the panel will try to connect to the first access point which can be found that
supports EAP. In this situation however, a successful connection is not
guaranteed because the identified WAP may be connected to a RADIUS
server which does not support the specified EAP type and/or may not have
the proper user identities configured.
Identity: When pressed, the panel displays an on-screen keyboard which allows you
to enter an EAP Identity string which is how the panel identifies itself to the
Authentication (RADIUS) Server.
• This information is similar to a username used to login to a secured server
or workstation. This works in tandem with the Password string which is
similar to the password entered to gain access to a secured workstation.
Note: Typically, this is in the form of a username such as: jdoe@amx.com
• Use the on-screen keyboard’s Clear button to completely erase any
previously stored identity/username information.
Anonymous Identity: When pressed, the panel displays an on-screen keyboard which allows you
to enter an IT provided alpha-numeric string which is similar to the username
used as the identity but does not represent a real user.
• This information is used as a fictitious name which might be seen by
wireless preying eyes (such as sniffer programs) during the initial
connection and setup process between the panel and the Radius server. In
this way the real identity (username) will never be seen by anyone.
Note: Typically, this is in the form of a fictitious username such as:
anonymous@amx.com
• Use the on-screen keyboard’s Clear button to completely erase any
previously stored identity/username information.
Required Information:
- SSID (Network Name used by the Target WAP)
- Identity (similar to the Username used for network access)
- Password (similar to the Password used for network access)
- Inner Authentication Type (supported by Devicescape)
