AMX NXT-CV10 User Manual

Appendix B - Wireless Technology
188
10" Modero Touch Panels
How to Upload a Certificate File
1. Install the latest AMX USB LAN LINK driver onto your computer by installing the latest versions of
either TPDesign4 or NetLinx Studio2. This USB driver prepares your computer to properly communicate
with a directly connected G4 touch panel (MVP/CV7/CV10).
Refer to Step 1 from within the previous Step 1: Setup the Panel and PC for USB
Communication section on page 186.
2. Access the target panel's Protected Setup firmware page and configure the USB communication
parameters.
Refer to Step 2 from within the previous Step 2: Confirm the Installation of the USB Driver on the
PC section on page 186.
3. With the panel successfully communicating with target computer, launch the Certificate Upload Utility.
Familiarize yourself with the User Interface options (Certificate Utility User Interface).
4. Locate your certificate file by using the Browse button and navigating to the desired file type.
5. Use the drop-down arrow in the Local Address field to select communication through either the
computer's Ethernet port (Internet communication) or via the USB port (direct connection). If using an
Ethernet connection skip to step 8.
6. For a USB connection, select the 10.XX.XX.1 IP Address which corresponds to the virtual IP Address
assigned to the USB connection port on the computer.
7. For a USB connection, navigate to the Add IP Address field (bottom-right of the interface) and enter a
value of 1 greater than the virtual USB IP Address.
For example: If the virtual USB IP Address is 10.0.0.1 then you would add an address for the
directly connected panel of 10.0.0.2 (this is one greater than the USB address value detected by the
utility).
You can send a certificate to ONLY ONE directly connected panel (via USB). If using the
Ethernet port's IP Address, you can send a server certificate to multiple target panels.
8. For an Ethernet IP Address connection, select the IP Address which corresponds to the local
computer's Ethernet address.
9. Navigate to the Add IP Address field (bottom-right of the interface) and enter the IP Addresses of the
various target touch panels.
10. Click the Add button to complete the entry and add the new IP Address to the listing of available device
IP Addresses. Repeat this process for all subsequent device IP Addresses.
11. Once your list is complete, click on the File drop-down menu and select the Save option to launch a Save
dialog where you can assign a name to the current list of addresses and then save the information (as a
TXT (text) file) to a known location.
12. Select the target devices which be uploaded with the selected certificate. These can either be:
individually selected by toggling the box next to the Send entry (with the Type column).
selected as a group by clicking on the Check All radio box located at the top of the device IP
Address listing.
13. When you are ready to send the certificate file to the selected panels, click the Send button to initiate the
upload.
Once the Status field for each entry reads Done, your upload was successfully completed.
This application must be run from a local machine and should not be used from a
remote network location.

AMX NXT-CV10 Specifications

General

Dimensions (WxDxH)	283 x 84 x 202 mm
Ethernet LAN (RJ-45) ports	1
Pixel pitch	0.28 x 0.28 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Display brightness	350 cd/m²
Display resolution	800 x 480 pixels
Contrast ratio (typical)	350:1
USB Type-A downstream ports quantity	2
Certification	FCC 15 B, CE, EN60950
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
NVIDIA G-SYNC	No

Weight and Dimensions

Weight (without stand)	1200 g
