AMX NXT-CV10 User Manual

Programming
137
10" Modero Touch Panels
Border styles
The TPDesign4 Touch Panel Design program has pre-set border styles that are user selectable. TPD4 border
styles can ONLY be changed by using the name.
TPD4 Border Styles by Name
Border styles Border styles
None Diamond 55
AMX Elite -L Diamond 65
AMX Elite -M Diamond 75
AMX Elite -S Double Bevel -L
Bevel -L Double Bevel -M
Bevel -M Double Bevel -S
Bevel -S Double Line
Circle 15 Fuzzy
Circle 25 Glow-L
Circle 35 Help Down
Circle 45 Help Down Reversed
Circle 55 Menu Bottom Rounded 15
Circle 65 Menu Bottom Rounded 25
Circle 75 Menu Bottom Rounded 35
Circle 85 Menu Bottom Rounded 45
Circle 95 Menu Bottom Rounded 55
Circle 105 Menu Bottom Rounded 65
Circle 115 Menu Bottom Rounded 75
Circle 125 Menu Bottom Rounded 85
Circle 135 Menu Bottom Rounded 95
Circle 145 Menu Bottom Rounded 105
Circle 155 Menu Bottom Rounded 115
Circle 165 Menu Bottom Rounded 125
Circle 175 Menu Bottom Rounded 135
Circle 185 Menu Bottom Rounded 145
Circle 195 Menu Bottom Rounded 155
Cursor Bottom Menu Bottom Rounded 165
Cursor Bottom with Hole Menu Bottom Rounded 175
Cursor Top Menu Bottom Rounded 185
Cursor Top with Hole Menu Bottom Rounded 195
Cursor Left Menu Left Rounded 15
Cursor Left with Hole Menu Left Rounded 25
Cursor Right Menu Left Rounded 35
Cursor Right with Hole Menu Left Rounded 45
Custom Frame Menu Left Rounded 55
Diamond 15 Menu Left Rounded 65
Diamond 25 Menu Left Rounded 75
Diamond 35 Menu Left Rounded 85
Diamond 45 Menu Left Rounded 95
Menu Left Rounded 105 Menu Top Rounded 65
Menu Left Rounded 115 Menu Top Rounded 75
Menu Left Rounded 125 Menu Top Rounded 85
Menu Left Rounded 135 Menu Top Rounded 95
Menu Left Rounded 145 Menu Top Rounded 105
Menu Left Rounded 155 Menu Top Rounded 115
Menu Left Rounded 165 Menu Top Rounded 125
Menu Left Rounded 175 Menu Top Rounded 135
Menu Left Rounded 185 Menu Top Rounded 145
Menu Left Rounded 195 Menu Top Rounded 155
Menu Right Rounded 15 Menu Top Rounded 165
Menu Right Rounded 25 Menu Top Rounded 175
Menu Right Rounded 35 Menu Top Rounded 185
Menu Right Rounded 45 Menu Top Rounded 195

AMX NXT-CV10 Specifications

General

Dimensions (WxDxH)	283 x 84 x 202 mm
Ethernet LAN (RJ-45) ports	1
Pixel pitch	0.28 x 0.28 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Display brightness	350 cd/m²
Display resolution	800 x 480 pixels
Contrast ratio (typical)	350:1
USB Type-A downstream ports quantity	2
Certification	FCC 15 B, CE, EN60950
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
NVIDIA G-SYNC	No

Weight and Dimensions

Weight (without stand)	1200 g
