AMX NXT-CV10 User Manual

Introduction
3
10" Modero Touch Panels
The optional wireless solution includes an NXA-WC80211GCF internal Wi-Fi card that allows the
CV10 to communicate with a NetLinx Master via a standard 802.11g Wireless Access Point, and
an NXA-BASE/1 battery base kit that allows the NXT to function off the charge from the included
single NXT-BP battery.
CV10 panels feature programmable firmware that can be upgraded via either the Ethernet port,
wireless interface card, or the mini-USB port.
NXT-CV10 Product Specifications
The following table outlines the specifications for the 10" Widescreen Modero panels.
The Button Trim Ring is factory installed only on the FG2259-02 and FG2259-03
panel models.
NXT-CV10 Product Specifications
Dimensions (HWD): • NXA-RK10(optional): metal rack-mount with black matte finish:
(5 RU - rack units high)
8.72" x 19.0" x 0.50" (22.15 cm x 48.26 cm x 1.27 cm)
• NXD-CV10 (with faceplate): 7.96" x 11.16" x 3.32"
(20.22 cm x 28.34 cm x 8.43 cm)
• NXT-CV10 (Fully raised): 8.71" x 11.16" x 7.38"
(22.12 cm x 28.34 cm x 18.75 cm)
• NXT-CV10 (Fully lowered): 4.53" x 11.16" x 7.79"
(11.51 cm x 28.34 cm x 19.79 cm)
• CB-TP10 Conduit/Wallbox (optional): 9.23" x 10.90" x 3.40"
(23.44 cm x 27.69 cm x 8.64 cm)
Power Requirements
(stand-alone CV10):
• Constant current draw: 1.2 A @ 12 VDC (stand-alone)
• Startup current draw: 1.2 A @ 12 VDC (stand-alone)
Power Requirements
(CV10 and BASE/1):
• Constant current draw: 2.6 A @ 12 VDC
• Startup current draw: 3.9 A @ 12 VDC
Memory (factory default): • 64 MB SDRAM
• 64 MB Compact Flash (upgradeable to 1 GB - factory programmed)
Weight (stand-alone): • NXD-CV10: 2.65 lbs (1.20 kg)
• NXT-CV10: 4.75 lbs (2.15 kg)
Certifications: • FCC Part 15 Class B, CE, and IEC 60950
Panel LCD Parameters: • Aspect ratio: 16 x 9
• Brightness (luminance): 350 cd/m
2
• Channel transparency: 8-bit Alpha blending
• Contrast ratio: 250:1
• Display colors: 256 thousand colors (18-bit color depth)
• Dot/pixel pitch: 0.28 mm
• Panel type: TFT Color Active-Matrix
• Screen resolution: 800 x 480 pixels (HV) @ 60 Hz frame frequency
• Video format: NTSC, PAL, and SECAM
• Viewing angle (95° total viewing angle):
Vertical: + 45° (up from center) and - 65° (down from center)
Active Screen Area: • 8.74” x 5.24” (22.20cm x 13.32cm)
IR Reception Angle: • Horizontal: +
50° (left and right from center)
• Vertical: +
30° (up and down from center)
Supported Audio Sample
Rates:
• 48000Hz, 44100Hz, 32000Hz, 24000Hz, 22050Hz, 16000Hz, 12000Hz,
11025Hz, and 8000Hz.

AMX NXT-CV10 Specifications

General

Dimensions (WxDxH)	283 x 84 x 202 mm
Ethernet LAN (RJ-45) ports	1
Pixel pitch	0.28 x 0.28 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Display brightness	350 cd/m²
Display resolution	800 x 480 pixels
Contrast ratio (typical)	350:1
USB Type-A downstream ports quantity	2
Certification	FCC 15 B, CE, EN60950
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
NVIDIA G-SYNC	No

Weight and Dimensions

Weight (without stand)	1200 g
