AMX NXT-CV10 User Manual

Introduction
4
10" Modero Touch Panels
NXT-CV10 Product Specifications (Cont.)
Front Panel Components:
Light sensor: • Photosensitive light detector for automatic adjustment of the panel brightness
(a dim room results in a dimmer LCD display, and a bright room results in a
brighter LCD display).
Note: The light sensor can be adjusted via the Sensor Setup page (page 102).
Motion sensor (PIR): • Proximity Infrared Detector to wake the panel when the panel is approached.
• Activation range: +
45° (left and right from center) and + 20° (up and down
from center).
Note: This sensor can be adjusted via the Sensor Setup page (see page 102).
IR Receiver: • IR reception: 38 KHz IR frequency.
• The IR receiver is located beneath the translucent Front Setup button. When
an IR code is detected it is sent to the NetLinx Master as a push on the
appropriate AMX IR channel.
• IR receivers and transmitters on G4 panels share the device address number
of the panel.
Front setup access button: • Provides both access to the Setup and Calibration page and toggles the
panel between a "sleep" or "wake" state.
- When wired, "sleep" status means the backlight is Off.
- When battery operated, wireless "sleep" status means the touch panel
base is either Off or "suspended".
Microphone: • Used for intercom applications
(requires the NXA-AVB/ETHERNET Breakout Box for analog
communication)
Speakers: • Stereo output with a frequency response of 500 Hz - 7 KHz
LEDs: • 6 blue LEDs support On and Off
(On = Button pressed, Off = Button released).
- Both the LEDs and pushbuttons are not available with the NXT-CV10
panel (FG2259-01) containing no buttons.
Buttons: • 6 programmable pushbuttons
Rear Panel Components: (Side panel location on NXD-Wall Mount panels)
Mini-USB connector: • 5-pin Mini-USB connector used for programming, firmware update, and touch
panel file transfer between the PC and the target panel.
Note: When connecting the panel to PC using a CC-USB (or compatible)
cable, be sure to power the panel On before attempting to connect the USB
cable from the PC to the mini-USB port on the panel. Refer to the Configuring
and Using USB with a Virtual Master section on page 51 for more
information.
Stereo Output connector: • Stereo output through a 3.5mm mini-jack (for use with external speakers or
headphones).
Ethernet 10/100 port: • RJ-45 port for 10/100 Mbps communication. The Ethernet port automatically
negotiates the connection speed (10 Mbps or 100 Mbps), and whether to use
half duplex or full duplex mode.
• CV10 panels communicate with the NetLinx Master using the ICSP protocol
over Ethernet.
Ethernet 10/100 LEDs: • LEDs show communication activity and connection information:
A-activity - Yellow LED lights when receiving or transmitting Ethernet data
packets.
L-link - Green LED lights when the Ethernet cables are connected and
terminated correctly.
USB connector: • Type-A USB port can connect an external keyboard or mouse device for use
with Virtual PC applications.
Note: External USB input devices (keyboard or mouse) must be plugged into
the rear/side USB connector before the unit is powered-up. The panel will not
detect these USB input devices until the unit cycles power.

AMX NXT-CV10 Specifications

General

Dimensions (WxDxH)	283 x 84 x 202 mm
Ethernet LAN (RJ-45) ports	1
Pixel pitch	0.28 x 0.28 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	10 \
Display brightness	350 cd/m²
Display resolution	800 x 480 pixels
Contrast ratio (typical)	350:1
USB Type-A downstream ports quantity	2
Certification	FCC 15 B, CE, EN60950
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	20 - 85 %
NVIDIA G-SYNC	No

Weight and Dimensions

Weight (without stand)	1200 g
