Firmware Pages and Descriptions
128
10" Modero Touch Panels
Refer to the Step 2: Choose a Master Connection Mode Setting section on page 67 for more detailed
information on using the System Settings page.
System Settings Page Elements (Cont.)
IP Address (Cont.)
Subnet Mask Sets a subnetwork address to the panel.
• Subnetwork mask is the technique used by the IP protocol to filter messages into a
particular network segment (Subnet).
Gateway Sets a gateway value to the panel.
• Gateway is a computer that either performs protocol conversion between different types
of networks/applications or acts as a go-between two or more networks that use the
same protocols.
Host Name Sets the host name of the panel.
Primary DNS Sets the address of the primary DNS server used for host name lookups.
• DNS (Domain Name System) is software that lets users locate computers on a local
network or the Internet (TCP/IP network) by host and domain. The DNS server
maintains a database of host names for its’ domain and their corresponding IP
Addresses.
Secondary DNS Sets a secondary DNS value to the panel.
Domain Sets the unique name on the Internet to the panel for DNS look-up.
The panel belongs to the DNS domain.
Ethernet Mode Sets the speed of the Ethernet connection to the panel.
Choices are: Auto, 10 Half Duplex, 10 Full Duplex, 100 Half Duplex, or 100 Full
Duplex.
MAC Address Displays a read-only field that is factory set by AMX for the built-in Ethernet interface.
Master Connection: Sets the NetLinx Master communication values:
Type Sets the NetLinx Master to communicate with the panel via either USB or Ethernet. This
is based on the cable connection from the rear. ICSNet is not a supported option on
this panel.
• Ethernet is a CAT-5 cable (10/100Base T terminated in an RJ-45 connector) used to
network computers together and is used in most LAN (local area networks). This
description is also used to refer to both wired and wireless communication.
• USB option cannot be used on Modero panels which are not equipped with a rear USB
port.
Mode Cycles between the different connection modes (URL, Listen, and Auto)
(ETHERNET Only - disabled when USB is selected)
• URL - In this mode, enter the IP/URL, Master Port Number, and username/password (if
used) on the Master. The System Number field is read-only because the panel obtains
this information from the communicating Master.
• Listen - In this mode, add the Modero panel address into the URL List in NetLinx Studio
and set the connection mode to Listen. This mode allows the Modero touch panel to
"listen" for the Master’s communication signals. The System Number and Master IP/
URL fields are red-only.
• Auto - In this mode, enter the System Number and a username/password
(if applicable). This mode is used when both the panel and the NetLinx Master are on
the same Subnet and the Master has its UDP feature enabled. The Master IP/URL field
is read-only.
System Number Allows you to enter a system number. Default value is 0 (zero).
(ETHERNET Only - disabled when USB is selected)
Master IP/URL Sets the Master IP or URL of the NetLinx Master.
(ETHERNET Only - disabled when USB is selected)
Master Port
Number
Allows you to enter the port number used with the NetLinx Master.
• Default value is 1319. (ETHERNET Only - disabled when USB is selected)
Username/
Password
If the target Master has been previously secured, enter the alpha-numeric string (into
each field) assigned to a pre-configured user profile on the Master.
This profile should have the pre-defined level of access/configuration rights.
To Next Page
