Spectrum Analyzer Commands 4-11 :TRACe Subsystem
S412E PM PN: 10580-00319 Rev. N 4-45
:TRACe{1|2|3}:LOAD:DISPlay[:STATe] OFF|ON|0|1
:TRACe{1|2|3}:LOAD:DISPlay[:STATe]?
Title: Trace View State
Description: Specifies whether the specified recall trace should be displayable
(visible) or hidden. TRACe1 corresponds to Trace A, TRACe2
corresponds to Trace B, and TRACe3 corresponds to Trace C. Setting
the value to ON or 1 will set the specified trace visible. Setting the value
to OFF or 0 will set the specified trace hidden. Note that this command
is valid only if there is a trace recalled.
Parameter: OFF|ON|0|1
Parameter Type: <boolean>
Default Value: OFF
Example: To set Trace A to Blank:
:TRACe:LOAD:DISPlay OFF
:TRACe1:LOAD:DISPlay 0
To set Trace B to View:
:TRACe2:LOAD:DISPlay ON
:TRACe2:LOAD:DISPlay:STATe ON
:TRACe2:LOAd:DISPlay 1
Front Panel Access: Shift-5 (Trace), Trace [A/B/C], View Blank
Note
These SCPI commands are applicable only if the user selects the option to recall
the trace to Trace A and not show the live trace.
