Appendix A Specifications
A-1
(1) Common items
Item Specifications
Measurement interface
NRZ, DVB-SPI, DVB-ASI
Remote control interface
GPIB, RS-232C
Internal clock frequency
setting
Setting range: 1 kHz to 155 MHz, Resolution: 1 Hz, Accuracy:
±
10 ppm
Transmission/
measurement pattern
Pseudo-random code: PN9, PN9_REV, PN15, PN15_REV, PN23,
PN23_REV, ALL“0”, ALL“1”, “1010”
Synchronization establish condition:
•
NRZ: 50 bits +N bits (N: number of stages, “0”
when fixed), when normal
•
DVB-SPI, SVB-ASI: 8
×
(8 + N) bits, when normal
Synchronization loss condition: when 6 error bits of 64 bits detected.
Error addition
Manual, Continuous (10
–2
, 10
–3
, 10
–4
, 10
–5
, 10
–6
, 10
–7
)
Measurement
time/number of bits
Measurement time (000h00m01s00 to 999h59m59s90)
Number of measurement bits (10
3
to 10
15
)
Repeat
AUTOSYNC
ON, OFF
Burst
Disable, Enable
Status indicator LED
Counting, Sync Loss, Signal Loss, Errors
Screen display
[1] Switch between “Error rate” and “Number of errors/total count”
[2] Over Flow display
[3] Error display
[4] Passed (elapsed) time/left (remaining) time display
[5] Current/Last display
Display screen control
Screen display OFF: None or 1, 5, 10, 20, 30, 40, 50, 60 (min)
Brightness adjustment: 25%, 50%, 75%, 100%
Auto save of setting data
Saves the set parameters just before power-off and sets them automati-
cally at the next power-on.
Power supply
Rated Voltage: AC 100 to 120 V or 200 to 240 V *
Rated Frequency: 50 to 60 Hz
Power consumption
50 VA or less
Operating temperature
0 to 50
°
C
Operating humidity
0 to 80% (No condensation)
External dimensions
426 (W)
×
88 (H)
×
451 (D) mm, excluding protrusions
Mass
7 kg or less
*
：
Operating voltage: within the range of +10% to –15% from the rated
voltage (Max. 250 V)
