Section 4 Operation
4-10
4.2.4 Auto Sync setting (Auto Sync)
Set measurement method when sync loss detected during measurement.
With this function set to On, measurement is stopped when synchroniza-
tion is lost and restarts measurement when re-synchronization is estab-
lished. All counters are cleared at this time.
When set to Off, measurement continues without establishing
re-synchronization. However, if sync-loss occurred, Sync Loss lamp does
not go on.
Select “Auto Sync” on the main menu screen to perform setting.
Sync loss occurs when the MP8931A detects 6 error bits out of 64 bits.
If the measurement object is a signal of the lower error rate than that of
sync loss condition at Auto Sync On, the measurement may not be per-
formed due to alternative repeating of sync loss and sync gain at burst
error.
Auto Sync
Off
Off
On
<Procedure>
1. Select measurement method at sync loss detection during measure-
ment by using the
∧
and
∨
keys on the Auto Sync setting
items. Press [Enter] to finalize the setting.
When this setting is performed during measurement, measurement
is restarted and the menu closes. When this setting is performed
while measurement is stopped, the measurement menu is displayed
again.
4.2.5 Output On/Off setting (Output)
Enable/disable the output of the output terminal for each interface. Set
to Disable to disable output in case of using the MP8931A for input only.
Output terminal is fixed to Low level when this item is set to Disable.
Output function of interface not selected is disabled, regardless of the
setting for this item.
Select “Output” on the main menu screen to perform setting.
Output
Enable
Disable
Enable
<Procedure>
1. Select enable/disable of output terminal for each interface by using
the
∧
and
∨
keys on the Output setting items. Press [En-
ter] to finalize the setting.
