4.2.10 Output function of NRZ interface setting
Set output parameters when using NRZ interface.
Select “NRZ Output*” on the main menu screen to perform setting.
FREQ 10,000,000
Level TTL
FREQ 155,000,000
Level TTL
Data Positive
Clock Rise
<Procedure>
1. Select setting item by using the
∧
and
∨
keys on the NRZ
Output* setting items. Press [Enter] or
>
to display the item to
be set.
(1) Frequency setting
Set the output frequency, ranging 1 kHz to 155 MHz in 1 Hz steps.
Select “FREQ” on the NRZ output menu screen to perform setting.
NRZ Frequency
010,000,000Hz
<Procedure>
1. Select “FREQ” by using the
∧
and
∨
keys on the NRZ
Output* setting screen.
2. Press [Enter] or
>
to display the FREQ setting screen.
3. Move the cursor to the digit to be set by using the
<
and
>
keys.
4. Increase/decrease the count at the digit with the cursor by using
the
∧
and
∨
keys.
Count can be increased/decreased over the current and upper
digits.
5. Repeat Steps 3 and 4 to set the desired frequency. Press [En-
ter] to finalize the setting.
When this setting is performed during NRZ measurement,
measurement is restarted and the menu closes. When this
setting is performed while measurement is stopped or during
DVB-SPI or DVB-ASI measurement, the NRZ output menu is
displayed again.
