Section 5 Remote Control
5-2
5.1 Outline
The MP8931A supports remote control to perform measurement auto-
matically by using an external controller. For this purpose, the
MP8931A is equipped with GPIB interface (IEEE std 488.2-1987) and
RS-232C interface as standard.
The MP8931A has the following interface functions:
Control of all functions except power switch, [Local] key, etc.
Readout of all setting conditions and measured results
Configuration of automatic measuring system in combination with PC
or other measuring instruments
Following is an example of a system-up:
GPIB
PRINTER
MP8931A
P
