4.2 Setting Parameters
4-11
4.2.6 Monitoring On/Off setting (Monitor)
Enable/disable the output of the monitoring terminal that outputs signal
input from the input terminal. This function is enabled when DVB-SPI
or DVB-ASI interface is selected.
Set this function in case of connecting the MP8931A to other device.
Monitoring terminal is set to high-impedance state when this function is
set to Disable.
Monitoring terminal function of interface not selected becomes
high-impedance state, regardless of setting for this function.
Select “Monitor” on the main menu screen to perform setting.
Monitor
Enable
Disable
Enable
<Procedure>
1. Select enable/disable of monitoring terminal output by using the
∧
and
∨
keys on the Monitor setting items. Press [Enter] to
finalize the setting.
