Appendix C Performance Test Result Sheet
C-1
Model Name: MP8931A Bit Error Rate Tester
Serial No.: ______________________________
Ambient Temperature: _____________
°
C
Relative Humidity _____________ %
•
NRZ Output Interface (Common for Data and Clock)
Output Level Specifications Result
−
0.9 V (ECL High)
±
0.2 V
−
1.7 V (ECL Low)
±
0.2 V
+2.5 V (TTL High)
±
0.3 V
0 V (TTL Low)
±
0.3 V
•
DVB-ASI Output Interface
Output Level Specifications Result
800 mV (p-p)
±
80 mV
•
DVB-SPI Output Interface
Output Level Specifications Result
1.125 to 1.35 V
(Offset Voltage)
−−−
247 to 454 mV
(Differential Voltage)
−−−
