4.2 Setting Parameters
4-13
(2) Input level setting
Set input level.
Select “Level” on the external clock input menu screen to perform
setting.
<Procedure>
1. Select “Level” by using the
and
keys on the EXT
Clock* setting screen.
2. Press [Enter] or
to display the Level setting items.
3. Select level to be input by using the
and
keys.
Press [Enter] to finalize the setting.
When this setting is performed during measurement, meas-
urement is restarted and the menu closes. When this setting is
performed while measurement is stopped, the external clock
input menu is displayed again.
(3) Termination resistor setting
Set termination resistor.
Select “Termination” on the external clock input menu screen to
perform setting.
<Procedure>
1. Select “Termination” by using the
and
keys on the
EXT Clock* setting screen.
2. Press [Enter] or
to display the Termination setting items.
3. Select termination resistor by using the
and
keys.
Press [Enter] to finalize the setting.
When this setting is performed during measurement, meas-
urement is restarted and the menu closes. When this setting is
performed while measurement is stopped, the external clock
input menu is displayed again.
