4.2 Setting Parameters
4-33
Select “Data Rate” on the DVB-ASI menu screen to perform setting.
<Procedure>
1. Select “Data Rate” by using the
and
keys on the
DVB-ASI* setting screen.
2. Press [Enter] or
to display the Data Rate setting items.
3. Select output data rate by using the
and
keys.
Press [Enter] to finalize the setting.
When this setting is performed during DVB-ASI measurement,
measurement is restarted and the menu closes. When this
setting is performed while measurement is stopped or during
NRZ or DVB-SPI measurement, the DVB-ASI menu is dis-
played again.
To Next Page
