Anybus CompactCom 40 User Manual

Anybus Module Objects 101 (258)
Instance Attributes (Instance #5, Gateway Address)
Value is used after module reset.
# Name Access Data Type Description
1 Name Get Array of
CHAR
“Gateway”
(Multilingual, see page 106)
2 Data type Get UINT8 04h (= UINT8)
3 Number of elements Get UINT8 04h (four elements)
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set Array of
UINT8
If read, the actual value will be received. If written, the written
value is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
6 Configured Value Get Array of
UINT8
Holds the configured value, which will be written to attribute #5
after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
This attribute should not be set by the application at every power on, as this would cause
certification problems.
Instance Attributes (Instance #6, DHCP Enable)
Value is used after module reset.
# Name Access Data Type Description
1 Name Get Array of
CHAR
“DHCP”
(Multilingual, see page 106)
2 Data type Get UINT8 08h (= ENUM)
3 Number of elements Get UINT8 01h (one element)
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set ENUM If read, the actual value will be received. If written, the written
value is reflected in attribute #6 until a reset.
(Multilingual, see page 106)
Value String Meaning
00h “Disable” DHCP disabled (default)
01h “Enable” DHCP enabled
6 Configured Value Get ENUM Holds the configured value, which will be written to attribute #5
after the module has been reset.
Value String Meaning
00h “Disable” DHCP disabled
01h “Enable” DHCP enabled
Do not set this unless the end user explicitly would like to turn DHCP on. Normally the
PROFINET IO Controller assigns the IP address.
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
