Anybus CompactCom 40 User Manual

Anybus Module Objects 102 (258)
Instance Attributes (Instance #9, DNS1)
This instance holds the address to the primary DNS server. Changes are valid after reset.
# Name Access Data Type Description
1 Name Get Array of
CHAR
“DNS1”
(Multilingual, see page 106)
2 Data type Get UINT8 04h (= UINT8)
3 Number of elements Get UINT8 04h (four elements)
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set Array of
UINT8
If read, the actual value will be received. If written, the written
value is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
6 Configured Value Get Array of
UINT8
Holds the configured value, which will be written to attribute #5
after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Instance Attributes (Instance #10, DNS2)
This instance holds the address to the secondary DNS server. Changes are valid after reset.
# Name Access Data Type Description
1 Name Get Array of
CHAR
“DNS2”
(Multilingual, see page 106)
2 Data type Get UINT8 04h (= UINT8)
3 Number of elements Get UINT8 04h (four elements)
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set Array of
UINT8
If read, the actual value will be received. If written, the written
value is reflected in attribute #6 until a reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
6 Configured Value Get Array of
UINT8
Holds the configured value, which will be written to attribute #5
after the module has been reset.
Valid range: 0.0.0.0 - 255.255.255.255 (Default =0.0.0.0)
Instance Attributes (Instance #11, Host name)
This instance holds the host name of the module. Changes are valid after reset.
# Name Access Data Type Description
1 Name Get Array of
CHAR
“Host name”
(Multilingual, see page 106)
2 Data type Get UINT8 07h (= CHAR)
3 Number of elements Get UINT8 40h (64 elements)
4 Descriptor Get UINT8 07h (read/write/shared access)
5 Value Get/Set Array of
CHAR
If read, the actual value will be received. If written, the written val-
ue is reflected in attribute #6 until a reset.
Host name, 64 characters
6 Configured Value Get Array of
CHAR
Holds the configured value, which will be written to attribute #5
after the module has been reset.
Host name, 64 characters
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
