Anybus CompactCom 40 User Manual

Anybus Module Objects 106 (258)
Instance Attributes (Instance #21, F-Address)
This instance holds the F-Address, which is the PROFIsafe address for the safety module. This instance has
no effect unless the attribute #1 (Safety enabled) is set to TRUE in the Functional Safety host object (instance
#1). If the attribute is set to FALSE in the Functional Safety host object the application is advised to hide this
instance to the end-user. See Functional Safety Object (E8h), p. 172
If this value is changed by the host application during runtime, a reset is required in order for changes to have
effect.
# Name Access Data Type Description
1 Name Get Array of
CHAR
“F-Adress”
(Multilingual, see page 106)
2 Data type Get UINT8 05h (= UINT16)
3 Number of elements Get UINT8 01h (one elements)
4 Descriptor Get UINT8 03h (read/write access)
5 Value Get/Set UINT16 F-Address set by the host application.
Range: 1 - 65534 (Default: 1)
6 Configured value Get/Set UINT16 The configured value that will be used after restart
Multilingual Strings
The instance names and enumeration strings in this object are multilingual, and are translated based on the
current language settings as follows:
Instance English German Spanish Italian French
3 IP address IP-Adresse Dirección IP Indirizzo IP Adresse IP
4 Subnet mask Subnetz-
maske
Masac.
subred
Sottorete Sous-réseau
5
Gateway Gateway Pasarela Gateway Passerelle
6 DHCP DHCP DHCP DHCP DHCP
Enable Einschalten Activado Abilitato Activé
Disable Ausschalten Desactivado Disabilitato Désactivé
7
Comm 1 Komm 1 Comu 1 Connessione
1
Comm 1
8 Comm 2 Komm 2 Comu 2 Connessione
2
Comm 2
9 DNS1 DNS 1 DNS Primaria DNS1 DNS1
10 DNS2 DNS 2 DNS
Secundia.
DNS2 DNS2
11 Host name Host name Nombre Host Nome Host Nom hôte
12 Domain name Domain name Nobre
Domain
Nome
Dominio
Dom
Domaine
13 SMTP Server SMTP Server Servidor
SMTP
Server SMTP SMTP
serveur
14 SMTP User SMTP User Usuario
SMTP
Utente SMTP SMTP utilisa.
15 SMTP Pswd SMTP PSWD Clave SMTP Password
SMTP
SMTP mt
passe
20 Station name Stationsname Nom.
Estacion
Nome
Stazione
Nom Station
21 F-Address F-Adresse Dirección-F Indirizzo-F F-Adresse
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
