Anybus CompactCom 40 User Manual

Host Application Objects 186 (258)
Extended
• If an attribute is not implemented, the default value will be used.
• The Anybus module in itself does not alter its behavior based on the value of attributes #13 and #14. The
host application has to implement the corresponding functionality..
• The module is preprogrammed with a valid Mac address. To use that address, do not implement attrib-
utes #17 and #18.
# Name Access Data Type Default
Value
Comment
4 MaxAr Get UINT32 0000 0003h Max. no.of simultaneous ARs.
(Range 1... 3)
5
(Reserved)
- - -
Reserved for future use
6
7 Record Data Mode Get UINT8 00h This setting affects how Record Data requests
are treated, and holds a bit field as follows:
Bit 0:Index 0... 7FFFh:
0: Normal Mode
1: Transparent Mode
Bit 1:Index AFF0h... AFFFh:
Reserved (replaced with the command IM_Op-
tions, see Network PROFINET IO Object (0Eh),
p. 133)
10 I&M Hardware
Revision
Get UINT16 Hardware
Rev.
I&M0 Parameter:
Hardware revision of device; FFFFh indicates
availability of profile specific information
If not implemented, the value of attribute #11
(Hardware version) in the Application Object
(FFh), will be used. If this attribute is not imple-
mented, the default value will be used.
11 I&M Software
Revision
Get Array of
CHAR
Software
Rev.
I&M0 Parameter:
Software revision of device.
Byte: Value: Meaning:
0: “V” Official release
“R” Revision
“P” Prototype
“U” Under test
“T” Test Device
1: 0... 255 Major Version
2: 0... 255 Minor Version
3: 0... 255 Internal Change
Please note that version V255.255.255 indi-
cates availability of profile specific information.
If not implemented, the value of attribute #10
(Firmware version) in the Application Object
(FFh), will be used. If this attribute is not imple-
mented, the default value will be used.
12 I&M Revision
Counter
Get UINT16 0000h I&M0 Parameter:
Revision counter of device; a changed value
marks a change of the hardware or its
parameters.
13 I&M Profile ID Get UINT16 0000h (Non
Profile
Device)
I&M0 Parameter:
If the application supports a specific profile, the
Profile ID must be defined here. It shall equal
the API number for the profile..
Please not that: this will not change the behavior
of the module, since it does not handle profiles.
14 I&M Profile Specific
Type
Get UINT16 Generic
Profile:
0004h (Com-
munication
Module)
I&M0 Parameter:
If the application supports a specific profile, the
profile specific type must be defined here (value
is defined by the profile).
Please not that: this will not change the behavior
of the module, since it does not handle profiles.
15-16 (Reserved)
- - -
Reserved, not used
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
