Appendix H: Backward Compatibility 241 (258)
H.4.5 Network Configuration Object (04h)
The instances in the Network Configuration Object have been rearranged for the Ethernet
based modules for consistency. Network specific instances are moved to instance number 20
and onwards. This is done to increase the number of instances in the section that is not network
specific.
If the host application is using any of the parameters below, the software must be updated to
use the new instance numbers.
Parameter Name 30-series Instance # 40-series Instance #
DNS1 8 9
DNS2 9 10
Host Name 10 11
Domain Name 11 12
SMTP Server 12 13
SMTP User 13 14
SMTP Password 14 15
Station Name 15 20
F-Address 20 21
Function Tag 16 Parameter removed
Location Tag 17 Parameter removed
Installation Date 18 Parameter removed
Description 19 Parameter removed
The following instances are removed in the 40-series. They are only possible to set via the
network.
• Instance #16 in 30-series, Function Tag
• Instance #17 in 30-series, Location Tag
• Instance #18 in 30-series, Installation Date
• Instance #19 in 30-series, Description
H.4.6 Network PROFINET IO Object (0Eh)
Attribute 30-series 40-series Change/Action/Comment
#3, Last OffLineInd
ReasonCode
-
Removed Attribute removed in the 40-series. Since the
command Ar_Offline_Ind is removed, this at-
tribute makes no sense.
If the host application is accessing this attrib-
ute, it will receive an error response when us-
ing the 40-series.
#9, ProfinetIoStack
Init ErrorCode
-
Removed Attribute removed in the 40-series.
If the host application is accessing this attrib-
ute, it will receive an error response when us-
ing the 40-series.
H.4.7 I&M4
I&M4 is removed in the 40-series. Writeable I&M records in GSD must be updated (see GSD
section below).
H.4.8 LED Indications
Changes has been made regarding the specification of the LED indications. See tables below
for differences.
Anybus
®
CompactCom
™
40 PROFINET IRT Network Guide SCM-1202-023 EN 1.8
