the right input source. Usually its name is AV or Composite. When in doubt,
try all of them.
Then check whether you’ve swapped the resistors. Connect the 470Ω resistor
to pin D7 and the 1kΩ resistor to D9. Also, make sure the resistors have the
right values.
If you see a distorted video signal, make sure you haven’t accidentally used
NTSC instead of PAL or vice versa. Also, check all solder joints on the modified
RCA cable. When in doubt, add more solder.
Exercises
• Use the TVout library to visualize some other sensor’s data. You can try
to build the parking-distance control from Chapter 5, Sensing the World
Around Us, on page 77, using the TVout library.
• Modify the TV thermometer so that it switches between degrees Celsius
and degrees Fahrenheit every few seconds. Don’t just change the text;
change the graphics, too.
Chapter 8. Generating Video Signals with an Arduino • 144
report erratum • discuss
www.it-ebooks.info

Arduino uno Specifications

General

Form factor	Arduino
Certification	RoHS, FC, CE
Processor model	-
Processor frequency	- MHz
Microcontroller model	ATmega328
Microcontroller frequency	16 MHz
DC input voltage	7-12 V
Operating voltage	5 V
DC current per I/O pin	40 mA
Flash memory	0.032 MB
Maximum internal memory	- GB
SRAM (Static Random Access Memory)	2 KB
EEPROM (Electrically Erasable Programmable Read-Only Memory)	1 KB
Wi-Fi	No
Number of analog I/O pins	6
Number of digital I/O pins	14

Weight and Dimensions

Board dimensions	53.4 x 68.6 mm
