Aruba 2930M - Uplink Port Specifications; Physical; Environmental

Stacking Module
Non-operating relative
humidity:
15% to 90% at 65°C (149°F)
Maximum operating altitude: 3.0 km (10,000 ft)
Non-operating altitude: 4.6 km (15,000 ft)
Uplink port specifications
Physical
Product Weight Width Depth Height
JL078A 0.15 kg (0.34 lb) 74.2 mm (2.92 in) 129.3 mm (5.09 in) 27.7 mm (1.09 in)
JL081A 0.17 kg (0.38 lb) 74.2 mm (2.92 in) 129.3 mm (5.09 in) 27.7 mm (1.09 in)
JL083A 0.17 kg (0.38 lb) 74.2 mm (2.92 in) 130.8 mm (5.15 in) 27.7 mm (1.09 in)
Environmental
Uplink port Module
Operating temperature: 0°C to 55°C (32°F to 131°F)
Relative humidity: 15% to 95% at 40°C (104°F)
noncondensing
Non-operating temperature: -40°C to 70°C (-40°F to 158°F)
Non-operating relative humidity: 15% to 90% at 65°C (149°F)
Maximum operating altitude: 3.0 km (10,000 ft)
Non-operating altitude: 4.6 km (15,000 ft)
Chapter 7 Specifications 87
