ASCOM I62 - 3 Programming the I62 Vowifi Handset; Winpdm; Ims2

TD 92675GB
10 January 2011/ Ver. A
Configuration Manual
Ascom i62 VoWiFi Handset
7
3 Programming the i62 VoWiFi Handset
This chapter describes how to configure handsets in three different ways:
• It is possible to configure the i62 handset by inserting it into a Desktop Programmer DP1
cradle connected via USB to the WinPDM.
• It is possible to configure the i62 handset via over-the-air (OTA) using the Device
Manager in the IMS2.
Note: Requires that the IP address to the IMS2 has been configured in the handset. The
IP address is configured using WinPDM or via the handset’s Admin menu.
• It is possible to configure the basic network settings of the i62 handset via its Admin
menu. See 9 Administration on page 61 for more information about the settings that
can be made.
It is recommended to use the Device Manager in IMS2 to configure handsets in a large
system. The reason is that it enables to install, upgrade and configure a large amount of
handsets simultaneously. Another benefit is that the collection of the handsets from the
user is not needed.
The WinPDM enables configuration of one handset at the time inserted in the Desktop
Programmer (DP1) connected via USB to the administrator’s computer.
It is also possible to upgrade the handset’s software via an TFTP server
1
and is
recommended for software upgrade over-the-air (OTA) in small systems when no IMS2 is
available.
Tip: It is recommended to use templates when configuring handsets. By using a template,
the same configuration can easily be applied to many handsets simultaneously.
3.1 WinPDM
The WinPDM runs on a PC and is used for configuring the handset as follows:
• Connect a DP1 Desktop Programmer cradle via USB to the computer running WinPDM.
•Start WinPDM.
• Place the handset in this cradle connected to WinPDM.
For instructions on how to install and use the WinPDM, see Installation and Operation
Manual, Portable Device Manager (PDM), Windows Version, TD 92325GB.
Figure 2. Configuration of Handsets via WinPDM
3.2 IMS2
The IMS2 runs on an ELISE2 module.
1.If TFTP server is used, it is only possible to upload software to the handset. Additional configuration, such as
parameter settings, is performed via WinPDM or IMS2.
WinPDM
