TD 92675GB
10 January 2011/ Ver. A
Configuration Manual
Ascom i62 VoWiFi Handset
15
1 Open WinPDM or the Device Manager in the IMS2.
2In the Numbers tab, select the handset you want to save as a template.
3 Make a right-click and select "Use as a template...". Enter a descriptive name for the
template.
4The Edit template window is opened. By default, all parameters are selected and are
saved when clicking "OK".
If one or more parameters should be excluded, remove them by clearing the checkbox
next to the parameter.
Some parameters are user specific. If it is decided to apply this type of template to
several handsets, it is recommended to exclude the following parameters:
• User display text - A text string displayed in idle mode. The parameter is located
directly under "Settings".
• Phone lock PIN code - The security code used to unlock the keypad. The parameter
is located under Settings > Locks.
• Endpoint ID - The identity/name of the user registered in the PBX. The parameter
is located under VoIP > General.
5Click "OK".
4.4.5 Synchronizing a Handset with WinPDM
After installing and saving a handset, it will be synchronized each time it is connected to the
WinPDM. The synchronization transfers parameter changes between the handset and the
WinPDM and vice versa as follows:
• If a parameter has been changed in the handset, it will be transferred to the WinPDM/
IMS2.
• If a parameter has been changed in the WinPDM/IMS2 while the handset was
disconnected, it will be transferred to the handset.
If the same parameter has been changed in both the WinPDM/IMS2 and the handset, the
value in WinPDM/IMS2 will be transferred to the handset.
4.4.6 Configure Handset without Saving It in WinPDM
It is possible to configure a handset without saving it in the WinPDM. An unsaved handset
do not have the symbol in the Saved column. The settings in the handset can be
synchronized and saved in the WinPDM later on. However, it is recommended to save the
handset in WinPDM if backup is needed. For example when a handset needs to be replaced.
1 Put the handset in the DP1 cradle
2 Open WinPDM.
3In the Numbers tab, select the unsaved handset you want to configure.
4 Select Number > Edit parameters.
5The Edit parameters window is opened. Edit the parameters of the handset and click
"OK".
6 Remove the handset from the DP1 cradle. The handset is no longer visible in the
WinPDM and the settings are only saved in the handset.
