TD 92675GB
10 January 2011/ Ver. A
Configuration Manual
Ascom i62 VoWiFi Handset
10
2 Click "Device Manager". You might be prompted to log on the Device Manager.
3 Select the Templates tab and click "New". The New template window is opened.
4In the Device type and Parameter version drop-down lists, select the corresponding
device type and parameter version to use, respectively.
5In the Name field, enter a descriptive name of the template.
6Click "OK".
7 Set the following network parameters:
• Network settings
1
(located under Network > Network A, B, C, or D)
• VoIP settings
2
(located under VOIP)
• Syslog settings
3
(if any) (located under Device > General)
• Unite settings
4
(located under Device > Unite)
8 Click "OK" to save the template.
Tip: See Appendix A for tip on how to work with templates when using both WinPDM and
IMS2.
4.1.2 Create a Common Template in the IMS2
Create another template with the common VoWiFi handset settings applicable to all
handsets (exclude the parameters and security settings configured in the Network
template). This template contains for example, hidden menu items in the display, certain
level of ring signal and vibrators.
Note: Only select the parameters that are changed, if all parameters are selected the system
performance decreases.
1 Open a webbrowser and enter the address to the IMS2.
2 Click "Device Manager".
3 Select the Templates tab and click "New".
4 In the Device Type and Parameter version drop-down lists, select the corresponding
device type and parameter version to use, respectively.
5 In the Name field, enter a descriptive name of the template.
6 Set the specific parameters. See section 4.4 Configure a Handset with a Template on
page 13 for more information.
4.1.3 Create Numbers in the IMS2
Create a range of Numbers and apply the templates previously created in the IMS2.
IMPORTANT: Do not add numbers already used because these handsets already exist in the
system although not saved in the Device Manager in IMS2. The Device Manager will
overwrite the existing parameters in the handset.
Note: The parameter version of the template must be equal to or less than the selected
parameter version.
1 Open a web browser and enter the address to the IMS2.
2 Click "Device Manager".
1. All required system settings for the WLAN. For example SSID and Security mode.
2.For example VoIP protocol, Gatekeeper IP address or SIP proxy IP address used to access the PBX.
3.The parameter "Syslog" must be enabled in order to set the "Syslog IP address".
4.IIP address and password (if any) to the IMS2.
