Atmel ATmega128 User Manual

263
2467S–AVR–07/09
ATmega128
GNDEN Input Ground the negative
input to comparator
when true
00
HOLD Input Sample & Hold signal.
Sample analog signal
when low. Hold signal
when high. If gain
stages are used, this
signal must go active
when ACLK is high.
11
IREFEN Input Enables Band-gap
reference as AREF
signal to DAC
00
MUXEN_7 Input Input Mux bit 7 0 0
MUXEN_6 Input Input Mux bit 6 0 0
MUXEN_5 Input Input Mux bit 5 0 0
MUXEN_4 Input Input Mux bit 4 0 0
MUXEN_3 Input Input Mux bit 3 0 0
MUXEN_2 Input Input Mux bit 2 0 0
MUXEN_1 Input Input Mux bit 1 0 0
MUXEN_0 Input Input Mux bit 0 1 1
NEGSEL_2 Input Input Mux for negative
input for differential
signal, bit 2
00
NEGSEL_1 Input Input Mux for negative
input for differential
signal, bit 1
00
NEGSEL_0 Input Input Mux for negative
input for differential
signal, bit 0
00
PASSEN Input Enable pass-gate of
gain stages.
11
PRECH Input Precharge output latch
of comparator. (Active
low)
11
Table 104. Boundary-scan Signals for the ADC (Continued)
Signal
Name
Direction
as Seen
from the
ADC Description
Recommen-
ded Input
when not
in Use
Output Values when
Recommended Inputs
are Used, and CPU is
not Using the ADC
