Figure 206. ADC Current vs. AV
CC
(ADC at 50 kHz)
Figure 207. ADC Current vs. AV
CC
(ADC at 1 MHz)
ADC CURRENT vs. A V
CC
ADC AT 50KHz
85 °C
25 °C
-40 °C
0
100
200
300
400
500
600
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
AREF CURRENT vs. A V
CC
85 °C
25 °C
-40 °C
0
50
100
150
200
250
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
