Atmel ATmega128 User Manual

334
2467S–AVR–07/09
ATmega128
Figure 162. Active Supply Current vs. Frequency (1 - 20 MHz)
Figure 163. Active Supply Current vs. V
CC
(Internal RC Oscillator, 1 MHz)
ACTIVE SUPPLY CURRENT vs. FREQUENCY
1 - 20 MHz
5.0 V
4.5 V
0
5
10
15
20
25
30
35
40
45
0 2 4 6 8 101214161820
Frequency (MHz)
I
CC
(mA)
2.7 V
3.0 V
3.3 V
3.6 V
4.0 V
ACTIVE SUPPLY CURRENT vs. V
CC
INTERNAL RC OSCILLATOR, 1 MHz
85 ˚C
25 ˚C
-40 ˚C
1.5
2
2.5
3
3.5
4
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(mA)
