Atmel ATmega128 User Manual

358
2467S–AVR–07/09
ATmega128
Current Consumption
in Reset and Reset
Pulse width
Figure 210. Reset Supply Current vs. V
CC
(0.1 - 1.0 MHz, Excluding Current Through The
Reset Pull-up)
Figure 211. Reset Supply Current vs. V
CC
(1 - 20 MHz, Excluding Current Through The Reset
Pull-up)
RESET SUPPLY CURRENT vs. V
CC
EXCLUDING CURRENT THROUGH THE RESET PULLUP
5.5 V
5.0 V
4.5 V
4.0 V
3.6 V
3.3 V
3.0 V
2.7 V
0
0.5
1
1.5
2
2.5
3
3.5
4
4.5
0 0.1 0.2 0.3 0.4 0.5 0.6 0.7 0.8 0.9 1
Frequency (MHz)
I
CC
(mA)
RESET SUPPLY CURRENT vs. V
CC
1 - 20 MHz, EXCLUDING CURRENT THROUGH THE RESET PULLUP
5.5 V
5.0 V
4.5 V
4.0 V
3.6 V
3.3 V
3.0 V
2.7 V
0
5
10
15
20
25
30
35
40
0 2 4 6 8 101214161820
Frequency (MHz)
I
CC
(mA)
