359
2467S–AVR–07/09
ATmega128
Figure 212.
Reset Pull-up Resistor C
urrent vs. R
eset Pin Voltag
e (V
CC
= 5.0V)
Figure 213.
Reset Pull-up Resistor C
urrent vs. R
eset Pin Voltag
e (V
CC
= 2.7V
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
V
CC
= 5V
85 °C
25 °C
-40 °C
0
20
40
60
80
100
120
0123456
V
RESET
(V)
I
RESET
(uA)
RESET PULL-UP RESISTOR CURRENT vs. RESET PIN VOLTAGE
V
CC
= 2.7V
85 °C
25 °C
-40 °C
0
10
20
30
40
50
60
0
0.5
1
1.5
2
2.5
3
V
RESET
(V)
I
RESET
(uA)
358
360
