Atmel ATmega128

351
2467S–AVR–07/09
ATmega128
Figure 196. Calibrated 2 MHz RC Oscillator Frequency vs. Temperature
Figure 197. Calibrated 2 MHz RC Oscillator Frequency vs. V
CC
CALIBRATED 2MHz RC OSCILLATOR FREQUENCY vs. TEMPERATURE
5.5 V
5.0 V
4.5 V
4.0 V
3.6 V
3.3 V
2.7 V
1.75
1.8
1.85
1.9
1.95
2
2.05
-60 -40 -20 0 20 40 60 80 100
Temperature
F
RC
(MHz)
CALIBRATED 2MHz RC OSCILLATOR FREQUENCY vs. Vcc
85 ˚C
25 ˚C
-40 ˚C
1.8
1.85
1.9
1.95
2
2.05
2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
F
RC
(MHz)
