303
2467S–AVR–07/09
ATmega128
Figure 145.
.SPI Serial Programm
ing Wavefor
ms
T
able 128.
Minimum Wait Delay before Writing t
he Next Flash or EEPROM Location, V
CC
= 5 V
± 10%
Symbol
Minimum W
ait Delay
t
WD_FUSE
4.5 ms
t
WD_FLASH
5 ms
t
WD_EEPROM
10 ms
t
WD_ERASE
10 ms
MSB
MSB
LSB
LSB
SERIAL CLOCK INPUT
(SCK)
SERIAL DA
T
A INPUT
(MOSI)
(MISO)
SAMPLE
SERIAL DA
T
A OUTPUT
302
304
