Individual indications
RemedyDescription/causeIndication on display
Check configuration.
FO configuration is incorrectFO configuration
Check configuration.
Configuration of the heater monitoring is incorrect.Heat.monitor.config.
Check configuration.
Configuration of the failure behaviour is incorrect.Fail.beh. config.
Check configuration.
Configuration of PID controller is incorrectConfig. PID controller
Configuration error (Collective signal 11)
Check hardware equipment/article number MCM.
Available version of the of 'MCM' (Motor Control and
Monitoring) electronics sub-assembly does not cor-
respond to target configuration.
IE MCM
Check hardware equipment/article number PSO.
Available version of the 'PSO' (Power Supply Op-
tions) electronics sub-assembly does not correspond
to the target configuration
IE PSO
Check hardware equipment/article number position
transmitter.
Internal error of position transmitter configuration
(for actual position recording)
IE config. pos. transm.
Check position transmitter parameters.
Available configuration does not correspond to the
target configuration.
IE parameter config.
Hydraulics fault (Collective signal 12)
Check oil level.
Oil level too lowOil level
Check hydraulic system.
Oil leakage occurredOil leakage
Check hydraulic system.Permissible running time of the electric motor for
hydraulic pump exceeded.
Motor running time
Check hydraulic system.
Excessive pressure risePressure rise
Test/connect phases.When connecting to a 3-phase network: One of the
phases L1, L2 or L3 is missing.
Phase fault
●
Cool down, wait.
●
If the fault indication display persists after cool-
ing down:
-
Set selector switch to position Local con-
trol (LOCAL) and reset fault indication via
push button RESET.
●
Check fuses.
Motor protection tripped
Thermal fault
Wrong oper. cmd (Collective signal 13)
Correct operation command, i.e. delete and set
anew.
An incorrect operation command is available at I/O
interface REMOTE1.
Incorr. cmd REMOTE1
Correct operation command, i.e. delete and set
anew.
An incorrect operation command is available at I/O
interface REMOTE2.
Incorr. cmd REMOTE2
Correct operation command.
An incorrect operation command is available at the
fieldbus interface.
Command fieldbus
Verify availability of function (Activation M0212
parameter)
Operation commands to setpoint positions are not
available (function disabled)
Setpoint pos. disabled
Internal error (Collective signal 14)
Check motor protection monitoring.
Motor protetction monitoring is defectiveIE mot. prot. monitor
Replace selector switch.
Internal error selector switch defectiveIE selector switch
Check power supply.
Internal error of phase monitoringIE phase monitoring
●
Check power supply (level and wiring).
●
Check power supply unit.
Internal error:
The internal 24 V AC voltage supply of the controls
has exceeded the power supply limits.
The 24 V AC voltage supply is used to control the
reversing contactors, to assess the thermoswitches,
to supply the internal actuator heater and, as an
option, to generate the 115 V AC supply for the
customer.
IE 24 V AC
Check switchgear control.
Internal error output defective (switchgear control)IE output defective
Check actuator.
Internal error position transmitter (for actual position
recording)
IE position transmitter
Check logic.
Internal error of 'Logic' electronics sub-assemblyIE logic
Check fieldbus interface.
Internal error of 'Fieldbus' electronics sub-assemblyIE fieldbus
126
Actuator controls
Corrective action ACV 01.2/ACVExC 01.2
