AUMA ACVExC 01.2 Series User Manual

Individual indications
RemedyDescription/causeIndication on display
Check MWG.
Internal error of 'MWG' (Magnetic Limit and Torque
Transmitter) electronics sub-assembly
IE MWG
Check local controls.
Internal error of 'LC' (Local Controls) electronics
sub-assembly
IE LC
Check MWG.Internal error: Calibration of Hall sensor 1 – 5 of the
MWG is incorrect.
IE Hall 1 calibration –
IE Hall 5 calibration
Check MWG.
Calibration of MWG is incorrectIE MWG calibration
Check device configuration.
Internal error, conflict of versionsIE version
Check device configuration.
Internal error EEPROMIE EEPROM
Check device configuration.
Internal error parameter (error during parameter
initialisation)
IE parameter
Check device configuration.
Internal error file accessIE file access
Check device configuration.
Error when accessing replacement parametersIE reserve backup
Check device configuration.
Internal error upon process data registrationIE registration
Check device configuration.
Internal error upon function block startupIE startup FB
Check device configuration.
Internal error upon electronics sub-assembly startupIE startup sub-assy
Check device configuration.
Error in the execution of LC firmwareIE LC exception
Check device configuration.
Error in the execution of logic firmwareIE logic exception
Check device configuration.
Error in the execution of MWG firmwareIE MWG exception
Check device configuration.
Error in the execution of fieldbus interface firmwareIE bus exception
Check device configuration.
Error when recording the end positions using the
MWG
IE MWG end positions
Internal warning (Collective signal 15)
Check heater.
Collective signal 15 (control unit)Wrn heater
Check 24 V DC inputs (DIN).The 24 V DC customer auxiliary supply to control
the digital inputs has failed.
24 V DC customer
Check internal 24 V DC voltage supply.The internal 24 V DC power supply of the controls
used to provide the electronics components (sub-
assemblies within the AC 01.2 controls and in the
actuator) has exceeded the power supply limits .
24 V DC internal
Reboot AUMATIC.
Internal warning: Replacement parameters are used
as no valid parameters are available (Remedy: Re-
boot controls/actuator)
Wrn res. data in use
Operate actuator fully in end positions OPEN and
CLOSED.
Actuator position feedback has not yet been refer-
enced to the end positions.
Wrn ref.actual position
Verify primary reduction gearing settings within the
actuator.
The current signal range of the position feedback
is outside the permissible range.
Wrn range act.pos.
Check position feedback.
Loss of signal of the actuator position feedback
signal
Wrn sign.loss act.pos.
Check system configuration.
Wrn event mark (internal system warning)Wrn event mark
Check system configuration.
Wrn Tm mark (internal system warning)Wrn Tm mark
Hydraulics warning (Collective signal 17)
Check hydraulic systemPressure of hydraulic accumulator lower than the
minimum value of the set accumulator pressure.
Operat. pressure min
Check hydraulic system.Permissible number of starts of the hydraulic pump
has been exceeded.
Pump starts
Check hydraulic system.Configuration of the accumulator pressure is incor-
rect.
Oper. press. config.
Config. error REMOTE (Collective signal 22)
●
Check I/O interface M0139 parameter.The
setting must correspond to the wiring diagram.
●
Check wiring.
●
Check I/O interface.
Available version of 'I/O interface' electronics sub-
assembly does not correspond to the target config-
uration.
IE I/O interface
127
Actuator controls
ACV 01.2/ACVExC 01.2 Corrective action
