The following screen shows Page 2 of the output of the status trunk command pertaining to this
same call. Note the signaling using port 5071 between Communication Manager and Session
Manager. Note the media is “ip-direct” from the IP Telephone (10.64.91.157) to the inside IP
address of Avaya SBCE (10.64.91.50) using codec G.729.
11:58:12 Call-ID: a4b93e1fefa7ee2746dfc32772f2cf69
/* Communication Manager sends re-INVITE to begin shuffle to ip-direct */
11:58:12 SIP>INVITE sips:+13035382177@10.64.91.50:5061;transport=tls
11:58:12 SIP>;gsid=45b06bf0-9976-11e7-9cb3-000c29e8354a;wlsscid=-270
11:58:12 SIP>f46a416660660;sipappsessionid=app-ybxwefkfgh8k SIP/2.0
11:58:12 Call-ID: a4b93e1fefa7ee2746dfc32772f2cf69
/* Final media path is ip-direct from answering IP (10.64.91.157) to inside of
SBC (10.64.91.50) */
11:58:12 G729A ss:off ps:20
rgn:2 [10.64.91.50]:35056
rgn:1 [10.64.91.157]:25426
11:58:12 G729 ss:off ps:20
rgn:1 [10.64.91.157]:25426
rgn:2 [10.64.91.50]:35056
11:58:12 SIP<SIP/2.0 100 Trying
11:58:12 Call-ID: a4b93e1fefa7ee2746dfc32772f2cf69
/* Communication Manager receives 200 OK with SDP, sends ACK with SDP */
11:58:12 SIP<SIP/2.0 200 OK
11:58:12 Call-ID: a4b93e1fefa7ee2746dfc32772f2cf69
11:58:12 SIP>ACK sips:+13035382177@10.64.91.50:5061;transport=tls;gs
11:58:12 SIP>id=45b06bf0-9976-11e7-9cb3-000c29e8354a;wlsscid=-270f46
11:58:12 SIP>a416660660;sipappsessionid=app-ybxwefkfgh8k SIP/2.0
11:58:12 Call-ID: a4b93e1fefa7ee2746dfc32772f2cf69
status trunk 2/1 Page 2 of 3
CALL CONTROL SIGNALING
Near-end Signaling Loc: PROCR
Signaling IP Address Port
Near-end: 10.64.91.65 : 5071
Far-end: 10.64.91.11 : 5071
H.245 Near:
H.245 Far:
H.245 Signaling Loc: H.245 Tunneled in Q.931? no
Audio Connection Type: ip-direct Authentication Type: None
Near-end Audio Loc: Codec Type: G.729
Audio IP Address Port
Near-end: 10.64.91.157 : 25426
Far-end: 10.64.91.50 : 35056
Video Near:
Video Far:
Video Port:
Video Near-end Codec: Video Far-end Codec:
