T1689 Technical Manual Rev 07 CDM Assembly
MV3000 Air Cooled DELTA MV3000e Controller
Page 119
5.8 MV3000E CONTROLLER
Mount the controller with four M5 self-tapping screws to the fixing dimensions in Appendix A: Dimensioned
Mechanical Drawings and torque setting as detailed in Appendix C: Recommended Torque Settings The
orientation of the controller will depend upon the application.
5.9 USER I/O TERMINATION PANEL
Mount the I/O panel with two M5 self-tapping screws to the fixing dimensions in Appendix A: Dimensioned
Mechanical Drawings, and torque setting as detailed in Appendix C: Recommended Torque Settings The
orientation of the I/O panel will depend upon the application; however it must be mounted adjacent to the
controller due to the length of the supplied ribbon cable.
5.10 MAINS VOLTAGE MONITOR
Mount the MVM unit with four M5 self-tapping screws to the fixing dimensions in Appendix A: Dimensioned
Mechanical Drawings, and torque setting as detailed in Appendix C: Recommended Torque Settings. The
orientation of the MVM unit will depend upon the application; however it must be mounted adjacent to the
controller due to the length of the supplied ribbon cable.
5.11 DRIVE DATA MANAGER (KEYPAD)
The Keypad can be mounted in a separate location from the controller within the enclosure. It should be
retained by the six M4 x 8 mm fixing screws and washers supplied.
Refer to the Instruction Sheets T1915 (Drive Data Manager Installation) and T1916 (Mounting Kit
Instructions) for details of the keypad and mounting.
5.12 DELTA RECTIFIER MODULE POWER CONNECTIONS
5.12.1 General
The a.c. and d.c. terminals on the modules are not suitable to support the weight of any attached cables. These
cables must have additional mechanical support;
The bending radii limits of all cables must be respected.
Refer to Appendix C: Recommended Torque Settings.
5.12.2 A.C. Terminals
NOTE: When tightening connections support the terminals to prevent twisting.
5.12.2.1 For GDR391 Rectifier Models
All a.c. power terminals are located on the front of the module (see Figure 2–14), and are marked R, S and T.
Each terminal provides an M10 stud, suitable for ring-crimp connection. Refer to Appendix C: Recommended
Torque Settings for torque settings.
5.12.2.2 For GDR633 Rectifier Models
All a.c. power terminals are located on the front of the module (see Figure 2–15), and are marked R1, S1, T1
and R2, S2, T2.
Each terminal provides two M10 studs, suitable for ring-crimp connection. Refer to Appendix C: Recommended
Torque Settings for torque settings.
