Avid Technology MV3000 DELTA User Manual

CDM Assembly T1689 Technical Manual Rev 07
Fitting enclosure Shrouds MV3000 Air Cooled DELTA
Page 128
5.19.6 MVM
Connections to the incoming a.c. supply are made to PL28, as shown in Figure 5–20. For further installation
instructions, see T1930.
Figure 5–20. - PL28 a.c. connections
5.20 FITTING ENCLOSURE SHROUDS
Overall enclosure shrouds should be fitted after all assembly and wiring have been completed. These will be
application specific, and must be fitted in accordance with the CDM designer’s instructions.
Pin 3 – T phase
Pin 2 – S phase
Pin 1 – R phase
