1.5 TYPICAL LAYOUT OF KEY DELTA COMPONENTS
A typical layout showing the key DELTA components that may be combined to build a CDM (Complete Drive
Module) is shown in Figure 1–3.
MVC3006-4003 Mains
Voltage Monitor
SMPS Module
MVC3003-40xx
50Z0126/xx
Sharing Reactor
DELTA Rectifier Module
MVRL1600
Drive Data Manager
TM
MVS3000-4001
MV3000e Controller
MVC3001-400x
DELTA Transistor Module
MVD500
User I/O Termination Panel
MVC3002-4001
Line reactor / Interbridge transformer, d.c. link reactor
Figure 1–3. – Typical layout of CDM
