Specification T1689 Technical Manual Rev 07
INSTALLATION ACCESSORIES (MECHANICAL) MV3000 Air Cooled DELTA
Page 70
2.15.3 Keypad Mounting Kit
Unit covered: MVS3001-4001
This kit allows the Drive Data Manager
TM
to be mounted to the vertical face of the drive enclosure.
Information is provided with the kit, detailing its specification and fitting instructions.
2.16 INSTALLATION ACCESSORIES (MECHANICAL)
2.16.1 DELTA Module Mounting Frames
The DELTA module mounting kit is a framework of cross members and brackets, which when installed in an
enclosure, provide support and fixing points for the modules. It is suitable for installation into standard Rittal
TS8 series enclosures.
The DELTA module mounting frames include four side supports and three cross members, complete with fixing
screws. Four frame widths are listed. The frames are supplied in a kit form. Lower guide plates are also
included with the kits.
2.16.2 Variations
The mounting kits are based on 600 mm (23.6 in) and 800 mm (31.5 in) deep enclosures. For each of these
depths there are four widths available:
• 600 mm (23.6 in) - to support up to two DELTA modules;
• 800 mm (31.5 in) - to support up to two DELTA modules;
• 1000 mm (39.4 in) - to support up to three DELTA modules.
• 1200 mm (47.2 in) – to support up to four DELTA modules.
The detailed part references for the DELTA module mounting frames for installation in Rittal TS8 enclosures are
listed in Table 2–38.
of DELTA
Width
Depth
kg (lb)
Table 2–38. – DELTA Module Mounting Frame Specifications
To Next Page
