Drive (CDM) Design T1689 Technical Manual Rev 07
Overview of Components Required MV3000 Air Cooled DELTA
Page 78
3.4 OVERVIEW OF COMPONENTS REQUIRED
The DELTA product range is a modular component sub-system that requires installation into an enclosure with
additional components to form a Complete Drive System (CDM). These additional components are specified
and purchased by the CDM designer / builder in addition to the parts supplied by GE Power Conversion.
3.4.1 DELTA Modules & Associated Components (DELTA Kit List)
A typical list will include:
Item
Drive Type
Component Description
Notes
Power modules
All versions
Air cooled transistor modules
Required
Dynamic Braking Units (DBs)
Optional
Rectifier fed
(DFE)
Air cooled rectifier modules Required
Wound components
All versions
Transistor module current sharing reactor
Required for
parallel
modules
Filter reactors (see Filters)
Required
Rectifier fed
(DFE)
d.c. link reactor
Optional
Rectifier inter-bridge reactor
Required for
parallel
rectifiers
Rectifier current sharing reactor
Required for
parallel
modules
All versions
Input line reactor
Required
Control components
All versions
MV3000e Controller
Required
MV3000e User I/O Termination Panel
MV3000e Switch Mode Power Supply(s) (SMPS)
Drive Data Manager (Keypad)
Optional
Rectifier fed
(DFE)
Mains Voltage Monitor (MVM)
Optional
AEM
Required
Accessories All versions
Ribbon cables
Required
Ribbon cable clamps
Mechanical All versions
DELTA power module mounting frame
Required
Module Cooling Fans
Required
‘Dirty Air’ Intake Duct
Optional
EMC Module to Module Link Plate
Required for
parallel
modules
Filters
All versions
Machine protection DV/DT Filter
Optional
AEM
AEM PWM Filter
Required
Common mode filter
Optional
