Avid Technology MV3000 DELTA User Manual

T1689 Technical Manual Rev 07 Appendix A: Dimensioned Mechanical Drawings
MV3000 Air Cooled DELTA Reactors, Inductors & Transformers
Page 169
10.6.4 Interbridge Transformers (cont’d)
Order No.
A
B
C
D
E
F
I
Detail A1 & A3
G
H
Detail A2
G
H
33Z0354/10
265
395
308
130
210
265
Fig 1
13
-
Fig 2
14
33
50Z0021/10
325
465
420
160
280
335
11
Fig 3
12
40
Fig 3
14
50
50Z0043/01
325
465
345
160
280
335
11
Fig 1
11
-
Fig 1
13
-
50Z0043/02
325
470
385
160
320
375
11
Fig 1
13
-
Fig 3
12
40
50Z0043/03
365
610
385
180
300
355
11
Fig 2
12
33
Fig 3
14
50
50Z0063/01
365
665
358
180
270
325
Fig 2
12
40
Fig 4
12
30
50Z0063/02
365
665
337
180
300
355
Fig 3
12
40
Fig 4
12
30
50Z0063/03
Details Upon request
50Z0063/04
Details Upon request
