T1689 Technical Manual Rev 07 Appendix B: Electrical Connection Diagrams
MV3000 Air Cooled DELTA RECTIFIER Network Bridge – POWER CONNECTIONS
Page 179
11.4.3.2 12 Pulse Supply, Dual Rectifier Modules with Standard Supply
GDR633, 872 or 1168
RECTIFIER MODULE
R1
S1
T1
R2
S2
T2
TB1
RECT 1+
RECT 2+
RECT 1 / 2-
DC LINK
REACTOR
DC+
DC-
3 PHASE
SUPPLY
Connections to user’s
“system healthy”
daisy chain circuit
GDR633, 872 or 1168
RECTIFIER MODULE
R1
S1
T1
R2
S2
T2
TB1
RECT 1+
RECT 2+
RECT 1 / 2-
A1
B1
C1
A2
B2
C2
SHARING
REACTOR
A1
B1
C1
A2
B2
C2
SHARING
REACTOR
A1
B1
C1
A2
B2
C2
SHARING
REACTOR
A1
B1
C1
A2
B2
C2
SHARING
REACTOR
